SMART TECHNOLOGY
Small but tough: Manufactured from the best raw materials, our Linear Low-Density Polyethylene (LLDPE) buoys are much more resistant to impact and adverse weather.
Red is red, not pink: The sun is no longer a problem, our buoys have a UV20 filter as standard, prolonging the colour for many years, more than 10 years. We comply with IALA RAL colours.
Take a Nap: This little big buoy has the facility to be stored vertically, a solution for small spaces.
FEATURES
High-Visivility up to 1.18m²
Float manufactured with Linear Low-Density Polyethylene (LLDPE) with a minimum thickness of 8 mm.
Minimum maintenance, its modular 2 parts makes it very easy to transport, install，repair and storage.
Lifting eyes connected to the mooring eye internally with SS rods.
PE Top mark.
This buoy can withstand sea currents of up to 6 knots.
Chromaticity according to IALA Recommendations.
Designed and manufactured according to IALA recommendations.
Technical Specifications
|
Superstructure |
|
|
Material |
LLDPE - Linear Low-Density Polyethylene. |
|
Thickness |
Minimum 8mm |
|
UV Resistant Grade |
UV20 |
|
Connection |
316L stainless-steel structure. |
|
Top Mark |
PE/SS316L |
|
Hardware |
SS316L |
|
Float |
|
|
Diameter |
1.0m |
|
Material |
LLDPE - Linear Low-Density Polyethylene. |
|
Thickness |
Minimum 8mm |
|
Filling |
Closed-cell Polyurethane |
|
Water Absorption |
Less than 1% |
|
UV Resistant Grade |
UV20 |
|
Joint Sections |
SS316L |
|
Tail Bottom |
|
|
Material |
LLDPE - Linear Low-Density Polyethylene. |
|
Counterweight |
Contrete, scalable according to stability |
|
Types |
Skirt |
|
Resistanse |
Internal rods |
|
Buoys Features |
|
|
Lifting Eyes |
2nos.SS lifting eyes welded to the mooning eye. |
|
Mooring Eyes |
1nos.SS mooring eye. |
|
Colour Life |
+10 years |
|
Life Spam |
+15 years |
|
Technical Data |
|
|
Float Diameter |
1000mm |
|
Visible Area |
1.18m² |
|
Focal Height |
2041mm |
|
Float Height |
870mm |
|
Draft |
454mm |
|
Total Height |
3078mm |
|
Total Weight |
0.225Tn |
|
Buoyancy |
2.2Kn |
|
Extra Weight |
100Kg=-125mm |
