SMART TECHNOLOGY
The Phecda Series Leading Light Devices is a new type of leading light device that meets the international IALA recommended standards, utilizing high-efficiency LED light sources and curve lenses, capable of achieving longer ranges at lower power.
The unique all-in-one solar + lithium battery power supply solution of the Phecda Series Leading Light Devices allows the device to reach an operational distance of over 15 nautical miles without the need for external power, which is rare in the industry, and the all-in-one structure also makes installation more convenient.
The optional built-in communication modules (BDS, GPRS, NB-IOT, CDMA) can be applied more flexibly in various scenarios.
The built-in Bluetooth short-range communication technology combined with a dedicated mobile app allows for detailed monitoring of the beacon's operational status and modification of operational parameters.
The all-aluminum alloy body + anti-corrosion surface coating can withstand harsh marine environments, providing high reliability and stability.
The Phecda-15B is also equipped with an auxiliary light strip output interface, allowing for synchronized control of the auxiliary light strip without the need for an additional controller.
Multi-angle selectable light source components can be more suitable for different widths of waterways, and the lamps are equipped with bird-proof devices.
The lamp design life exceeds 5 years and provides a 5-year free warranty period.
|
Technical Parameters |
|
|
Nominal Range |
15 nautical miles (T = 0.74) |
|
Nominal Voltage |
DC12V |
|
Silent Current |
＜20mA |
|
Dynamic Power Consumption |
3~10W |
|
Selectable Colors |
Red, Green, White |
|
Positioning Method |
BDS / GPS / BDS + GPS (optional) |
|
Telemetry Communication Method |
Long-distance Communication BDS / NB-IOT / CDMA / GPRS Short-distance Communication BLUETOOTH |
|
Daylight Threshold |
300+50 Lux(100~2000 Lux) |
|
Vertical Divergence Angle |
＞1.5° |
|
Horizontal Divergence Angle |
> 1.5 ° / 3 ° / 10 ° / 20 ° / 30 ° (Optional) |
|
Synchronous Mode |
Satellite Time Synchronization |
|
Bluetooth Effective Distance |
20 meters |
|
Alarm |
Over/Under Voltage, Light Failure, Position Offset, Temperature and Humidity, etc. |
|
Weight |
12.5kg |
|
Protection Level |
IP66/IP68 |
|
Operating Temperature |
-35℃~60℃ |
|
Optional Functions |
|
|
RF remote control function |
|
|
Telemetry communication method |
|
