FEATURES

---

International Compliance: The Merak series lanterns comply with international IALA recommendations and are available in a wide range of colors (red, green, yellow, white, and blue) to meet all global maritime signaling needs.



Durable and Modular Structure: With a compact and lightweight design of just 2.0 kg, the Merak 7A offers a robust and portable structure, capable of withstanding the most extreme weather conditions. Its unique modular system with watertight compartments ensures IP68 waterproofing, protecting the internal components from water and dust.



Energy-Efficient LED Technology: Equipped with high-quality, efficient LEDs, the Merak 7A ensures optimal visibility throughout its range while maintaining minimal power consumption without compromising brightness. Its energy stabilizer enhances operational reliability by eliminating issues such as poor contact and voltage drops.



NavLight Manager APP: The user-friendly app developed by Tenyn Ocean allows advanced programming of parameters such as range, rhythm, and consumption. Additionally, it offers short-range monitoring via the integrated Bluetooth 5.2 module, without the need to approach the equipment.



Communication Options: The Merak series is compatible with satellite communication modules, GPRS, GSM, IoT, and AIS, offering a wide range of solutions for customers. Our cloud-based software, NavLight Pro Manager, provides real-time visualization and complete control of the equipment.



Extended Lifespan and Warranty: Designed as a highly durable solution, the Merak 7A is built with premium materials, ensuring reliable performance for over 15 years in harsh marine conditions. Additionally, we offer an extended 5-year warranty, providing our customers with maximum peace of mind and confidence in their long-term investment.



Signal Output Control: The Merak 7A features a signal output identification control, capable of directly managing external signals, increasing its versatility and functionality.

 Technical Specifications

---

Luminous Range	up to 8nm (T=0.74)
Input Power	9-36Vdc
Peak Power Consumption	10W
Colours	R, G, W, Y & B
Positioning Method	GPS, Sat or GPS+Sat
Long-range Communication	Sat, IoT, GSM, GPRS
Short-range Communication	Bluetooth 5.2
Daylight Threshold	300 Lux (0-2000)
Horizontal Divergence	360°
Vertical Divergence	>8°
Synchronisation Method	GPS
Programming	Bluetooth 5.2
Alarms	Voltage, Impact, Temperature, Failure, humidity, etc.
Weight	2.0Kg
Watertightness	IP68
Operation Temperature	-35° to +60° C
